AUDIOENGINE - D1 24-BIT DAC/HEADPHONE AMP

Dac/Ampแบบตั้งโต๊ะมีOutput ทั้งRCA และช่องหูฟัง ต่อกับคอมพิวเตอร์ได้เลยไม่ต้องลงDriver

DAC type
Dual Mode USB and Optical (SPDIF)
Inputs
USB/Optical (SPDIF)

Outputs
RCA stereo/3.5mm headphone

D/A converter
AKM4396

Optical receiver
CS8416

USB controller
TI1020B

USB device class
Type 1.1 or above

Full-scale output
2.0V RMS

Output impedance
10 ohms

Power source
USB 5V

Power requirements
5V DC, 200mA

USB power filtering
2-stage redundant regulation

SNR
(DC to 20 kHz) >110dB

THD+N
(1kHz FS 96kS/s) <0.0025%

Crosstalk
-85db

USB transfer mode
Asynchronous (dual clock)

Frequency response
10Hz - 25KHz (+/- 0.5dB)

Input bit depth
16 bit, 24 bit

Input sample rate (USB)
32kHz-96kHz - native playback
188.2kHz, 192kHz - re-sampled to 96kHz for playback

Input sample rate (optical)
32kHz-192kHz - native playback

Product dimensions
3.5x4x1"

Shipping weight
1.0lbs (0.5kg)

Environmental
Operating Temperature: 32 to 95 degrees F
Non-operating Temp: -4 to 113 degrees F
Relative Humidity: 5% to 95% non-condensing

Included accessories
USB cable, 2ft
Setup Guide
Microfiber bag

D1 USB
The D1 utilizes the TI1020B USB controller, widely recognized as a standard for higher-end USB audio products. The D1 is powered directly from the USB bus and USB power is passed through two stages of regulation to ensure high stability and low noise.

D1 DAC
The D1 uses the AK4396 DAC, well regarded for its low noise and high fidelity. Due to the high signal-to-noise specs of the AK4396 and the added benefit of double redundancy power source conversion and filtering, the D1 presents impressive low noise and low distortion characteristics.

D1 Headphone
The D1 includes a headphone amp based on the TI OPA2134 low noise opamp. This headphone amp is able to provide low-impedance, high-fidelity audio to a wide range of headphones and supports headphones with impedance as low as 20 ohms.

Features
Desktop or portable digital-to-analog convertor
Mac or PC plug-and-play, no drivers to install
High-performance headphone amp included
USB and optical inputs
USB-powered, no separate power supply needed
Stream bit-perfect HD audio with low jitter
Based on high-performance AK4396 DAC

Works With
Any computer (Mac or PC)
Headphones
Apple TV or any product with optical outputs
Powered speakers
Any audio system with mini-jack or RCA inputs

What's in the box
(1) D1 DAC
(1) USB cable, 2ft (0.6m)
(1) Microfiber product bag
(1) Setup guide
(1) Product line brochure
